Blackmagic Design URSA Broadcast G2 Camera (Body Only)
GH₵100,450.00
Product Highlights
- 6K CMOS Sensor, Dual Native ISO
- 23" B4 Lens Mount & Active EF Mount
- 6K Blackmagic RAW Recording
- Records to ProRes, H.265264
- 12G-SDI Input & Output, GenlockTimecode
- 13 x Stops of Dynamic Range
- 2 x UHS-II SD, 2 x CFast 2.0 Slots
- Built-In 246-Stop ND Filters
- XLR Inputs, 3.5mm Audio Output
- ProRes Recording up to 1080p120
Specs
Blackmagic Design URSA Broadcast G2Specs
Imaging
| Lens Mount | B4 |
| Interchangeable Lens Mount | Yes |
| Lens Communication | Yes |
| Sensor Resolution | Not Specified by Manufacturer |
| Sensor Type | 23.1 x 12.99 mm (Medium Format) CMOS |
| Sensor Windowing | 4K (3840 x 2160) in 169 When Recording in Raw |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2 Stop (14), 4 Stop (116), 6 Stop (164) ND Filters |
| ISO Sensitivity | 400 to 3200 (Native) 100 to 25,600 (Expanded) |
| Shutter Type | Rolling Shutter |
| Gain | -6 to 18 dB |
| Advertised Dynamic Range | 13 Stops |
Internal Recording
| Raw Recording |
Blackmagic RAW 10-Bit 6144 x 3456 at 50 fps (65 to 483 MBs) 6144 x 2560 at 60 fps (49 to 359 MBs) 5376 x 3024 at 60 fps (51 to 371 MBs) 3728 x 3104 at 60 fps (36 to 265 MBs) 3840 x 2160 at 60 fps (32 to 190 MBs) 1920 x 1080 at 150 fps (5.2 to 47 MBs) |
| Recording Modes |
ProRes 422ProRes 422HQ 3840 x 2160p up to 60 fps (73.6 to 110 MBs) 1920 x 1080p up to 60 fps (18.4 to 27.5 MBs) 1920 x 1080p at 120 fps (18.4 to 27.5 MBs) H.265 3840 x 2160p up to 60 fps (3.2 to 7.8 MBs) H.264 1920 x 1080p up to 60 fps (1.8 to 7 MBs) |
| Audio Recording | ProRes 2-Channel 24-Bit 48 kHz |
| Still Image Support | Not Specified by Manufacturer |
External Recording
| IP Streaming | None |
Interface
| MediaMemory Card Slot | Dual Slot SDSDHCSDXC (UHS-II) Dual Slot CFast (CFast 2.0) |
| Video Connectors |
1 xBNC (12G-SDI) Output 1 xBNC (12G-SDI) Input 1 xBNC (12G-SDI) Monitor Output |
| Audio Connectors |
1 x18" 3.5 mm TRRS HeadphoneMicrophone Headphone InputOutput on Camera Body 2 x3-Pin XLR MicLine Level (+48 V Phantom Power) Input on Camera Body |
| Built-In Microphone Type | Stereo |
| Other IO |
1 xUSB Type-C USB 3.1 Gen 2 Video Output 1 xUSB Type-C Data Input 1 x2.5 mm LANC Control Output 1 xBNC Reference, Sync, Timecode Data Input 1 x12-Pin Hirose Camera Interface Control Output |
| Wireless Interfaces | Bluetooth Control |
Monitor
| Size | 4.0" |
| Display Type | Articulating Touchscreen LCD |
| Secondary Display | Side LCD Status Display |
EVF
| EVF | Optional, Not Included |
Power
| Battery Type | V-Mount |
| Power Connectors |
1 x4-Pin XLR Input 1 x4-Pin XLR (12 to 20 VDC) Output 1 x12-Pin Molex Input |
| Power Consumption | 100 W |
Environmental
| Operating Temperature | 32 to 104F 0 to 40C |
| Storage Temperature | -4 to 113F -20 to 45C |
| Operating Humidity | 0 to 90% |
Physical
| Tripod Mounting Thread | 3 x14"-20 Female (Bottom) |
| Material of Construction | Magnesium Alloy |
| Accessory Mount | 1 xARRIHirth Rosette |
| Dimensions | 10.95 x 9.93 x 5.9" 27.81 x 25.22 x 15cm |
| Weight | 7.83lb 3.55kg |
Packaging Info
| Package Weight | 11.4 lb |
| Box Dimensions (LxWxH) | 20.7 x 10.1 x 7.1" |
