RODE RODECaster Video All-in-One Production Console
GH₵17,725.00
Product Highlights
- Switcher with Integrated Audio Mixer
- 4 x HDMI & 2 x USB-C Inputs
- Supports up to 1080p60
- RTMP Streaming via Ethernet or Wi-Fi
- 20 x Audio Sources, 9 x Stereo Channels
- 9 x MixEffect Layers
- Digital USB Audio Ports
- 2 x Combo XLR-14", High-Gain Preamps
- Aphex VoxLab Audio Processing
- Bluetooth 5.3 and Wi-Fi 6 Connectivity
Specs
RODE RODECaster VideoSpecs
Mix Effects
| Available ME Layers | 9 ME |
| Effect Types | 2x Chroma Key |
| Downstream Keys | 2x Overlay |
| Audio Mixing | 20-Channel Mixing |
Processing
| Switching Type | Pushbutton |
| Processing Resolution | 1080p at 23.98242529.97305059.9460 |
| Color Processing | 8-Bit 444 RGB |
Input
| Number of Video Input Sources | 6 |
| Video Inputs | 4x HDMI (1.4b) 2x USB-C (UVC) |
| Input Video Format |
HDMI (81012-Bit 444422 RGB, YUV) 1080p at 23.98242529.97305059.9460 fps 1080i at 2529.9730 fps USB-C (444422 YUV) 1080p at 23.98242529.97305059.9460 fps |
| Audio Inputs | 2x Combo XLR-14" TRS 5x Proprietary (Shared with Video) |
| Embedded Audio Input | Wireless USB-C HDMI |
Output
| Video Output Channels | 2 |
| Video Outputs | 2x HDMI |
| Output Video Format |
HDMI (8-Bit 444 RGB, YUV) 1080p at 2425305060 fps |
| Audio Outputs | 2x 14" TRS 2x 14" TRS Line |
Connectivity
| InputsOutputs | 3x USB-C(Stereo) |
| Other IO | 1x RJ45 LAN |
| HDCP Support | No |
IP EncodingDecoding
| IP Video | 1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p Encoding |
| Transport Protocols | RTMP |
| Compatible Services | Facebook Live, Twitch, YouTube Live |
Internal Recording
| Recording Media | 1x microSD (Unspecified Type) |
| Recording Modes | 1920 x 1080p (H.264AVC) |
Display
| Display Size | 2" |
Hardware
| OS Compatibility | macOS 10.15 or LaterWindows 10 to 11 |
| Processor | Not Specified by Manufacturer |
| Wi-Fi | Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) |
| Bluetooth | 5.3 |
Power
| Power IO | 1x USB-C Input |
| Power Consumption | Power Supply 20 VDC at 3 A (60 W) |
General
| Dimensions | 12 x 5.2 x 2.4" 305.9 x 132 x 61.4mm |
| Weight | 2.8lb 1257g |
Packaging Info
| Package Weight | 5.35 lb |
| Box Dimensions (LxWxH) | 13.8 x 8.3 x 4.3" |
